High quality explosion-proof glass, high light transmittance, anti-violent, scratch-resistant, dust-proof and waterproof；

Professional chip and processing technology to ensure high image quality；

Industrial high-performance LCD screen ensures high image clarity, high brightness and stability of use;

The shell is made of high-strength steel, which is ultra-thin, beautiful and strong, and has excellent protection performance;

The surface is fine-grained, smooth and even, with good anti-rust and wear-resisting functions;

A variety of signal interfaces, supporting a variety of signal input / output;

Adopt industrial industrial control board, Android system.

Technical Parameter

Product model		US-AD*****
Screen parameters	Size	32”-65”	Audio system	Horn	2×5W(8Ω)
	Back type	Backlight integration	Audio system	Sound mode	standard
	Display Proportion	16：9	Output Interface	PC output interface	RJ45 1、USB 2
	Physical resolution	1920X1080	Output Interface	L/R Audio output	1 RCA X2
	Color depth	16.7M	Power consumption	Input voltage	C 100~240v 50/60HZ
	Viewing angle	R/L/U/D 89/89/89/89	Power consumption	Standby power / rated power	≤3W/≤180W
	Brightness	450 cd/㎡	Cabinet	Material	SPCC
	Contrast	5000:1	Cabinet	Exterior color	Black (default) gold silver
	Response time	5ms	External conditions	Working temperature / humidity	0℃~50℃/20%～80%
	Service time	60000 hours	External conditions	Storage temperature / humidity	-10℃~60℃/5–95%

Power consumption table

	18.5 inch	21.5 inch	27 inch	32 inch	43 inch	49 inch	55 inch	65 inch	75 inch	86 inch	98 inch
Standalone version	25W	30W	50W	70W	85W	100W	115W	180W	240W	380W	550W
Android system	25W	30W	50W	70W	85W	100W	115W	180W	240W	380W	550W
Low power consumption One machine series	38W	40W	50W	90W	100W	120W	135W	180W	260W	300W	500W
Desktop machine series	95W	98W	110W	150W	170W	190W	220W	250W	330W	390W	600W

Touch Panel Solutions

Standalone OS Solutions

Version

CPU

Internal Storage

Out Storage

Interface

System supporting

Display Version

E9-B11/ E9-BNC/E6J-AV

No storage

USB /HDD/SSD

HDMI/VGA/DVI/USB

Android /Windows/Linux OS

Standalone Version

Mstar V56

No storage

( 8G/16G available)

support SD card and USB Flash

HDMI/USB/SD

Only Standalone OS

Android OS Solution

Configuration	CPU	Chip architecture	Processor	Maximum resolution support	System Version	Storage
Basic level	A20	Cortex-A7	Dual-Core	1080P	Android 4.1	512Mb +8G
	A33	CortexTM-A7	Quad-core	1080P	Android 4.4	512Mb/1Gb +8G
	A64	Cortex-A53	Quad-core	1080P	Android 5.1	512Mb/1Gb +8G
Middle level	RK3128	Cortex-A7	Quad-Core	1080P	Android 6.0	512Mb/1Gb +8G
	RK3368	Coretex-A53	Octa-Core	2K/4K	Android 6.0	1Gb/2Gb +8G
	RK3188	Cortex A9	Quad-Core	2K	Android 6.0	1Gb/2Gb +8G
Top level	RK3288	Cortex-A17	Quad-Core	4K	Android 6.0	2Gb +8G
	RK3399	Cortex-A72	Dual-core +Quad-core	4K	Android 7.1	4Gb +16G
	Amlogic T960X	Cortex-A53	Quad-Core	4K	Android 7.1	2Gb+8G
