Infrared & Capacitive Touch

Wide-View Angle

Windows Ready

Narrow Bezel Display

Android Ready

24/7 Usage

Landscape & Portrait

IPS panel

55 inch Narrow Bezel LCD Video Wall



Download Narrow Bezel LCD Video Wall Catalogue

What is User Narrow Bezel LCD Video Wall ?

55 inch Narrow Bezel LCD Video Wall is a large visualization surface that is made by various LCD displays called ‘tiles’. Design of these individual displays is specifically for use in these applications . In other words it has much better quality than normal TV screens. Normal television sets are capable of working for a few hours day. While these specific panels are expected to work much more hours. Often 24/7 or even days continuously. And because the environments in which these video walls are deployed are sometimes critical, the up-time should be maximum possible.

Let’s watch some videos of 55 inch Narrow Bezel LCD Video Wall. You will be amazed by super high display quality!!!!

Above all, here we explore some of the most considerable features of “Narrow Bezel 55 inch LCD Video Wall“:

If you don’t have enough knowledge about LCD and LED display technologies, “Difference between LED and LCD in wall display” is surely a useful guide. Above all, here we explore some of the most considerable features of ” 55 inch Narrow Bezel LCD Video Wall “:

Narrow Bezel Width

Width of bezel in the 55″ LCD video walls is one of the most considered criterion in its structure which should be as thin as possible. Otherwise it would make an unpleasant visual experience for you. Modern LCD video wall tiles have a narrow bezel. In User, we have provided you LCD video walls featuring ultra narrow bezels and advanced picture enhancement technology. So it’ll let you have superb quality images proper for different business environment.

Beautiful Shapes of Video Wall

Multiple Inputs

Powerful interface supporting a wide range of audio and video inputs like SD card and USB Flash and outputs such as HDMI/VGA/DVI/USB. The USER manufacturer has considered fast dynamic picture without any delay or even frame loss to enhance the UX (user experience).

Centralized Terminal Management

A cloud-based system that provides real-time control and insights of smart advertisement players and video walls, enabling operators to remotely manage content, display schedule and other functions.

digital signage controls

Multiple Configuration

You can easily choose among basic level, middle level and top level. Different levels are various in processor from Dual-Core to Dual-Core. Its OS version is available Android 4.1 to Android 7.1 .Moreover we let you to choose your favorite OS between Android, Windows, Linux or standalone OS.

Various Wall Display Sizes

Choosing propriate wall display size based on your environment size is a signification factor in purchasing LCD video wall. There is no limit for you if you require this display solution for cinema, concert hall, university, stadium, shopping mall or etc.

LCD Videowall Screen Size

Automatic Switch Machine

If you are a busy person who forgets to turn off your 55 inch ultra-narrow bezel LCD video wall at night, this feature can save you from paying high-price electricity bill. Automatic switch machine will get an administrator schedule and act exactly based on your set time.

Intelligent Split Screen

Intelligent Split Screen is an attractive item in your 55 inch narrow bezel LCD video wall control software. It helps to take most benefit of your device and use each of its screens to display various visual content.

Intelligent Split Screen

3D Processing Kernel

3-Dimensional digital image processing kernel equipped in narrow bezel LCD video walls are for precise monitoring of more details.

Lifetime Technical Support

This is also a crucial support department in User Company. Counting over twenty technician and engineers to help service any issues that might occur during the life cycle of your displays. Our current final failure rate is below 1.7%. We strive on a daily basis to keep lowering these statistics. Our weekly meetings between our after sales and QC teams truly help us achieve these hard set goals.

24/7 Usage

As one the important features of 55″ narrow LCD video wall displays is to be able to work continuously for long hours and days. User Company video wall devices are built for 24/7 commercial use of uninterrupted work with the stable performance.

Front Maintenance

The maintenance of indoor and outdoor LCD video wall contains front maintenance. With the development in the LED screen industry, the pixel pitch of the LCD screen is smaller and smaller. As a result, it makes the maintenance easier and quicker and from the front side.



Operating system (OS):

Our 55″ narrow bezel LCD video wall series come with customized operating system that will put your hands to choose your preferred OS among Windows, Android or even standalone OS . In this way, you will supply pleasant user experience for your customers based on their interest.

Built-in mosaic controller

Built-in mosaic controller which is located on display panel, runs complicated shows quite precisely. In fact , it supports DMX512 and DMX-Over-Ethernet protocols to LED fixtures, conventional dimmable fixtures and automated lights. Mosaic Show Controllers also called MSC , offer up to 2048 channels of control from a single controller. Above all, to read more click here .

Automatic Color & Brightness Calibration

You can never have perfect color and brightness settings unless your bezel-free videowall isn’t equipped with automatic color & brightness calibration system. It means all of the panels need to be synchronized with the surrounding displays. Even a small deviation in color or brightness will make you disasters in display balance.

Automatic Calibration 2

Automatic Calibration 1

Eco-Friendly Power Timer

The Eco-friendly power timer lets you assign hourly, daily or weekly on and off times for screen. By this feature, the power is consumed as it is needed. Moreover it is be really effective in energy consumption.

100.000 Hours Lifespan

It’s estimated that lifespan of 55″ thin LCD video wall could be approximately 60,000 hours depending on the life of its backlighting bulb. Besides for LEDs have expected lifespan of twice more than LCDs about 100,000 hours.

Wide-Viewing Angle

Unlike a conventional display surface which it’s not possible to view the monitor at 178 degrees (side to side). User LCD display wall let you have this wide viewing angle keeping display brightness and contrast.

178 Wide View Angle

IPS Commercial Grade Panel

IPS (In-plane switching) is a screen technology for LCD monitors. This was designed to solve the unignorable limitations such as strong viewing angle dependence and low-quality color reproduction.

3 Years Warranty

User Company has 3 years of warranty for all the products in there will be a technical issue in your display systems. Usersdt Warranty covers the defects resulting from defective parts, materials or manufacturing. The device is considered defective if it fails to perform the functions as indicated in the operation manuals, technical specifications or any other similar documents supplied with the equipment, and the failure is due to internal device characteristics.

Specifications

Model 55” DID LCD Panel
 Bezel 0.88mm
LCD Panel Max Resolution Support 1920×1080(H×V)
Pixel Pitch 0.53025(H)×0.53025 (V)
Brightness (nits) 500 (cd/ m )
Contrast 4000:1
Response Time 8ms
Color 16.7M
Visual Angle (H/V) 178°(H) / 178°(V)
Image Contrast 16 : 9
Picture quality compensation LTI、CTI
Motion compensation AUTO MOVE
Filter 3D comb filtering,digital noise reduction
Video format PAL、NTSC

Video Wall Controller

(Built-in each Screen)

Computer centralized control interface RS232
Structure Border dimension 1.8mm
Net weight 25kg
Shell material Metal shell, anti-static,anti-magnetic,anti-strong electric field interference
Installation way Wall mount,floor standing mount,hanging mount

Configuration options

Option 1 Full HD 2K
Signal source Composite Video Input/(AV) CVBS(BNC) ×1
Digital signal input HDMI×1; 1920×1080@60Hz backward compatible
Computer signal input VGA(DB-15) ×1;1920×1080@60Hz backward compatible
Digital signal input DVI(DVI-I)×1;1080P(1920×1080) backward compatible
Composite Video Input/(AV) CVBS(BNC)x1
RS232 3
USB 1
Option 2 DP Looping 4K
Signal source Display Port(DP) 3840×2160@30Hz、3840×2160@20Hz、3840×2160@25Hz
HDMI 480p、576p、720p、1080i、1080p、2160p
DVI 480p、576p、720p、1080i、1080p

Input port



Display Port DP×1
PC-RGB 15 D-SUB×1
HDMI HDMI×1
DVI DVI×1
RS232 1
Output RS232 1
Display Port DP×1
